Speed Tablet Press Machine GZPK-65/71 High Output 462000 pcs/h Automatic Tablet Weight Control BB BBS Tooling
Gedetailleerde productomschrijving
| Aantal stations: |
65 (GZPK-65) / 71 (GZPK-71) |
Gereedschapsnorm: |
BB (GZPK-65) / BBS (GZPK-71) |
| Max hoofddruk: |
100 kN |
Max pre-druk: |
kN 20 |
| Maximale tabletdiameter (rond): |
13 mm |
Maximale tabletdiameter (onregelmatig): |
16 mm |
| Max vuldiepte: |
15 mm |
Max tablet dikte: |
6 mm |
| Max torentje snelheid: |
70 r/min |
Max productiecapaciteit: |
462.000 stuks/uur |
| Motorvermogen: |
11 kW |
Totale maat: |
1530 x 1250 x 1900 mm |
| Machinegewicht: |
4300 kg |
Compatibiliteit met tabletvorm: |
Rond, onregelmatig, dubbelzijdig gegraveerd |
| Controlesysteem: |
PLC met HMI-aanraakscherm |
Smering: |
Automatisch centraal olie- en vetsysteem |
| Markeren: |
speed tablet press machine, high output tablet compression, automatic tablet rejection system |
The TIANHE GZPK-65 and GZPK-71 represent the highest-output tier of our speed tablet press machine lineup, purpose-built for pharmaceutical and nutraceutical manufacturers requiring maximum throughput without compromising on tablet quality. Equipped with 65 and 71 stations respectively using BB and BBS international tooling standards, these machines deliver an industry-leading 462,000 tablets per hour in continuous production mode. The compact tablet size capability (up to 13
